Solef® 11010 PVDF is a typical thermoplastic material used as an additive in order to offer unique benefits to polymer resins, such as the elimination of melt fracture and the reduction of die buildup.

Due to its incompatibility with the majority of polymers and their fast movement in the molten flow during extrusion, Solef 11010 PVDF builds a thin coated layer on the metal surface of the die leading to a direct improvement of the processability of the extruded polymers (stabilization of flow instabilities).

Technical data sheet

Physical Properties

Property	Typical Value	Unit	Test Method
Density / Specific Gravity	1.75 to 1.80	-	ASTM D792
Melt Mass-Flow Rate (MFR) (230°C/5.0 kg)	4.0 to 8.0	g/10 min	ASTM D1238
Molding Shrinkage - Flow	2.0 to 3.0	%	-
Water Absorption (24 hr, 23°C)	< 0.040	%	ASTM D570

Mechanical Properties

Property	Typical Value	Unit	Test Method
Tensile Modulus (23°C, 2.00 mm)	800 to 1200	MPa	ASTM D638
Tensile Strength
- Yield, 23°C, 2.00 mm	20.0 to 35.0	MPa	ASTM D638
- Break, 23°C, 2.00 mm	20.0 to 40.0	MPa	ASTM D638
Tensile Elongation
- Yield, 23°C, 2.00 mm	10 to 12	%	ASTM D638
- Break, 23°C, 2.00 mm	200 to 600	%	ASTM D638
Coefficient of Friction			ASTM D1894
- vs. Itself - Dynamic	0.15 to 0.35	-
- vs. Itself - Static	0.20 to 0.40	-
Taber Abrasion Resistance (1000 Cycles, 1000 g, CS-10 Wheel)	5.00 to 15.0	mg	ASTM D4060

Impact Properties

Property	Typical Value	Unit	Test Method
Charpy Notched Impact Strength (23°C, 4.00 mm)	150 to 250	J/m	ASTM D6110

Hardness

Property	Typical Value	Unit	Test Method
Durometer Hardness (Shore D, 1 sec, 2.00 mm)	70 to 75	-	ASTM D2240

Thermal Properties

Property	Typical Value	Unit	Test Method
Glass Transition Temperature	-35.0	°C	ASTM D4065
Vicat Softening Temperature	90.0 to 105	°C	ASTM D1525
Melting Temperature	158 to 162	°C	ASTM D3418
Peak Crystallization Temperature (DSC)	115 to 130	°C	ASTM D3418
CLTE - Flow (0 to 40°C)	1.8E-4	cm/cm/°C	ASTM D696
Specific Heat			ASTM E968
- 23°C	1200	J/kg/°C
- 100°C	1600	J/kg/°C
Thermal Conductivity (23°C)	0.19	W/mK	ASTM C177
Crystallization Heat	30.0 to 40.0	J/g	ASTM D3417
Heat of Fusion	35.0 to 40.0	J/g	ASTM D3417

Electrical Properties

Property	Typical Value	Unit	Test Method
Surface Resistivity	> 1.0E+14	ohms	ASTM D257
Volume Resistivity	> 1.0E+14	ohms·cm	ASTM D257
Dielectric Strength (23°C, 1.00 mm)	20 to 25	kV/mm	ASTM D149
Dielectric Constant (23°C, 1 MHz)	7.00 to 10.0	-	ASTM D150
Dissipation Factor (23°C, 1 MHz)	0.20	-	ASTM D150

Flammability

Property	Typical Value	Unit	Test Method
Flame Rating (0.100 mm)	V-0	-	UL 94
Oxygen Index (3.00 mm)	44%	%	ASTM D2863

Product Functions

Low VOC
High Purity
High ESCR (Stress Crack Resist.)
Sour Gas Resistant
Acid Resistant
Mineral/Synthetic Oil Resistant
Detergent Resistant
Hydrolysis Resistant
Low Moisture Absorption
Piezoelectric Properties
Flame Retardant
Fatigue Resistant
High Hardness
High Stiffness
Creep Resistant
Good Impact Resistant
Low CLTE
UV Resistant
Radiation (Gamma) Resistant
Good Processing Stability
Autoclave Sterilizable (steam)
E-beam Sterilizable
Radiation Sterilizable
Ethylene Oxide Sterilizable
Heat Sterilizable
Good Thermal Stability
High Heat Resistant

Applications of Solef 11010/0001

Segments	Applications
Equipment & Parts	Piping & Tubing
