Solef 60512/0000
Leave your phone number, we will call you back immediately
Solef 6012 by Syensqo is a high molecular weight polyvinylidene fluoride homopolymer. It is a semi-crystalline and additive-free grade. Is suitable for processing by extrusion and compression molding. It has the intrinsic stability inherent to fluoropolymers even when exposed to harsh thermal, chemical and UV environments.
Technical data sheet
Physical
| Property | Typical Value | Unit | Test Method |
|---|---|---|---|
| Density / Specific Gravity | 1.75 to 1.80 | -- | ASTM D792 |
| Melt Mass-Flow Rate (MFR) (230°C/10.0 kg) | 2.5 to 4.0 | g/10 min | ASTM D1238 |
| Molding Shrinkage - Flow | 3.0 | % | -- |
| Water Absorption (24 hr, 23°C) | < 0.040 | % | ASTM D570 |
Mechanical
| Property | Typical Value | Unit | Test Method |
| Tensile Modulus (23°C, 2.00 mm) | 1250 to 1400 | MPa | ASTM D638 |
| Tensile Strength | |||
| Yield, 23°C, 2.00 mm | 34.0 to 40.0 | MPa | ASTM D638 |
| Break, 23°C, 2.00 mm | 34.0 to 40.0 | MPa | ASTM D638 |
| Tensile Elongation (%) | |||
| Yield, 23°C, 2.00 mm | 9.0 to 12 | % | ASTM D638 |
| Break, 23°C, 2.00 mm | 170 to 300 | % | ASTM D638 |
| Coefficient of Friction | |||
| vs. Itself - Dynamic | 0.20 to 0.30 | -- | ASTM D1894 |
| vs. Itself - Static
|
0.20 to 0.40 | -- | ASTM D1894 |
| Taber Abrasion Resistance | |||
| 1000 Cycles, 1000 g, CS-10 Wheel | 5.0 to 10.0 | mg | ASTM D4060 |
Impact
| Property | Typical Value | Unit | Test Method |
| Notched Izod Impact (23°C, 4.00 mm) | 1000 |
|
ASTM D6110 |
Hardness
| Property | Typical Value | Unit | Test Method |
| Durometer Hardness (Shore D, 2.00 mm) | 70 | -- | ASTM D2240 |
Thermal
| Property | Typical Value | Unit | Test Method |
| Glass Transition Temperature | -40.0 | °C | ASTM D4065 |
| Vicat Softening Temperature | 167 |
|
ASTM D1525 |
| Melting Temperature | 170 to 174 | °C | ASTM D3418 |
| Peak Crystallization Temperature (DSC) | 142 to 146 |
|
ASTM D3418 |
| CLTE - Flow (0 to 40°C) | 1.3E-4 to 1.8E-4 | cm/cm/°C | ASTM D696 |
| Specific Heat | |||
| 23°C | 1200 | J/kg/°C | ASTM E968 |
| 100°C | 1600 |
|
ASTM E968 |
| Thermal Conductivity (23°C) | 0.19 | W/m/K | ASTM C177 |
| Crystallization Heat | 42.0 to 50.0 | J/g | ASTM D3417 |
| Heat of Fusion | 42.0 to 50.0 | J/g | ASTM D3418 |
Electrical
|
Property |
Typical Value | Unit | Test method |
| Surface Resistivity | > 1.0E+14 | ohms | ASTM D257 |
| Volume Resistivity | > 1.0E+14 | ohms·cm | ASTM D257 |
Product Functions
- Low VOC
- High Purity
- High ESCR (Stress Crack Resist.)
- Sour Gas Resistant
- Acid Resistant
- Mineral/Synthetic Oil Resistant
- Detergent Resistant
- Hydrolysis Resistant
- Low Moisture Absorption
- Piezoelectric Properties
- Flame Retardant
- Fatigue Resistant
- High Hardness
- High Stiffness
- Creep Resistant
- Good Impact Resistant
- Low CLTE
- UV Resistant
- Radiation (Gamma) Resistant
- Good Processing Stability
- Autoclave Sterilizable (steam)
- E-beam Sterilizable
- Radiation Sterilizable
- Ethylene Oxide Sterilizable
- Heat Sterilizable
- Good Thermal Stability
- High Heat Resistant
Applications of Solef 60512/0000
| Segments | Applications |
| Equipment & Parts | Piping & Tubing |
| Equipment & Parts | Subsea |
