3M™ Fluorinert™ Electronic Liquid FC-72
Key Features and Benefits of 3M™ Fluorinert™ Electronic Liquid FC-72
- Thermal Stability: Performs consistently in low-temperature environments.
- Chemical Stability: Resistant to chemical degradation, ensuring long-lasting use.
- Wide Liquid Range: Operates effectively across a broad temperature spectrum.
- Non-Conductive: Safe for applications involving electronic components.
- Narrow Boiling Range: Maintains consistent composition over time, minimizing fluid loss.
Recommended Applications
The 3M™ Fluorinert™ Electronic Liquid FC-72 is highly suitable for a variety of applications requiring precise and reliable heat transfer:
- Dielectric Bath
- Electronic Testing
- Heat Transfer
- Power Electronic Cooling
Technical Specifications
| Property | Value |
| Boiling Point (Celsius) | 56 ℃ |
| Boiling Point (Fahrenheit) | 133 ℉ |
| Density | 1.68 g/cm³ |
| Dielectric Strength Range | >35 kV, >40 kV |
| GWP (IPCC 2007) | >5000 (100 yr ITH) |
| Pour Point (Celsius) | -90 ℃ |
| Pour Point (Fahrenheit) | -130 ℉ |
| Net Weight (Imperial) | 14 lb, 44 lb |
| Net Weight (Metric) | 6.35 kg, 20 kg |
| Volume (Imperial) | 1 gal, 3.25 gal |
| Volume (Metric) | 3.79 L, 12.3 L |
Conclusion
The 3M™ Fluorinert™ Electronic Liquid FC-72 is the ideal choice for low-temperature heat transfer applications in the electronics and power industries. Its combination of thermal and chemical stability, along with its non-conductive properties, makes it a reliable fluid for maintaining performance in critical cooling systems.
