Kluberalfa DH 3-230 Description
- Kluberalfa lubricants, based on perfluorinated polyether (PFPE), were developed to fulfil lifetime lubrication under demanding conditions and offer a number of characteristics that make them highly suitable for such tasks.
- Kluberalfa DH 3-230 contain a PFPE oil mixture with excellent thermal stability and low evaporation rate. They are available with different viscosities to cover various temperature ranges
Benefits for your application
- Long component life across a wide service temperature range. Due to excellent thermal and chemical stability
- Many component materials can be used. Due to the good compatibility with plastics and elastomers.
Technical data of Kluberalfa DH 3-230.
Product Data | Klüberalfa DH 3-230 |
---|---|
Article number | 090140 |
NSF-H1 registration | - |
Chemical composition, type of oil | PFPE |
Lower service temperature | -25 °C / -13 °F |
Upper service temperature | 230 °C / 446 °F |
Density, DIN 51757, 20 °C | approx. 1.91 g/cm³ |
Refraction index, DIN 51423 pt. 02, at 20 °C | approx. 1.302 |
Kinematic viscosity, 40 °C | approx. 230 mm²/s |
Kinematic viscosity, 100 °C | approx. 24 mm²/s |
Viscosity index, DIN ISO 2909 | >= 120 |
Pour point, DIN ISO 3016 | <= -30 °C |
Minimum shelf life | 60 months |
Application of Klüberalfa DH 3-230:
Sintered Metal Components:
- Kluberalfa DH 3-230 oils are used for impregnating sintered metal plain bearings that operate at high temperatures and require long-term lubrication.
- Thanks to their exceptional thermal and chemical stability, additional lubrication with products like MIKROZELLA is typically not necessary.
Plastic Components:
- Kluberalfa DH 3-230 oils are suitable for lubricating both plastic components and metal-plastic sliding contact surfaces. These oils are clear, colourless, and odourless, and they do not form unwanted resins.
Material Compatibility:
- Kluberalfa DH 3-230 oils are generally considered neutral towards elastomers and plastics (except for perfluorinated rubber). As a result, they are not expected to have any adverse effects on the material.
- However, it is recommended to conduct compatibility tests with the specific materials, especially before implementing the lubricant in series applications. Ensuring compatibility is essential to avoid any potential issues with the materials.
Kluberalfa DH 3-230 Application notes
- Sintered metal components are impregnated by immersion in the Kluberalfa DH 3 oil. The oil bath can be heated up to a maximum of 80 °C, during which the immersion tank is subjected to a low vacuum of 0.1 to 0.001 bar, accelerating penetration.
- The sintered-metal component is completely filled with oil when no more air bubbles are expelled to the oil surface.
