Your requirements — our solution.
Klubersynth GEM 4-100 N is a synthetic high-performance gear and multipurpose oil based on polyalphaolefin satisfying the growing requirements and increasing power density of modern gears. Klubersynth GEM 4-100 N includes KlüberComp Lube Technology, i.e. it is based on especially high-grade raw materials and advanced additives, enabling maximum performance in the lubrication of all gear components.
Klubersynth GEM 4-100 N offers a much longer service life than mineral oils due to the excellent ageing and oxidation resistance of the selected raw materials; thus service intervals can be extended and maintenance costs reduced. The product's low foaming tendency and anti-corrosive properties enable problem-free gear operation. Freudenberg seals made of 72 NBR 902, 75 FKM 585, 75 FKM 260466 and 75 FKM 170055 are resistant to Klubersynth GEM 4-100 N. Leakage and oil contamination are prevented.
Your benefits at a glance
- High scuffing protection
- Excellent wear protection for gears and rolling bearings
- Good shear stability for reliable lubricant film formation
- High micropitting resistance
- Excellent ageing and oxidation resistance
- Wide service temperature range due to good viscosity-temperature behaviour
- Low foaming tendency
- Energy savings due to optimised friction behaviour
- Good elastomer compatibility
- Approvals by numerous gear OEMs
Product data Klubersynth GEM 4-100 N.
Marking acc. to DIN 51502 | CLP HC 100 |
Classification acc. to ISO 12925-1 | CKC 100 |
Lower service temperature | -40 °C / -40 °F |
Upper service temperature | 140 °C / 284 °F |
Density, based on DIN 51757) at 15 °C | approx. 850 kg/m³ |
Foam test, ASTM-D 892, ISO 6247, sequence I/24 °C | <= 100/10 ml |
Foam test, ASTM-D 892, ISO 6247, sequence II/ 93.5 °C | <= 100/10 ml |
Foam test, ASTM D 892, ISO 6247, sequence III/24°C | <= 100/10 ml |
Flash point, DIN EN ISO 2592, Cleveland, open-cup apparatus | >= 200 °C |
Kinematic viscosity, DIN 51562 pt. 01/ASTM D-445/ASTM D 7042, 40 °C | approx. 100 mm²/s |
Kinematic viscosity, DIN 51562 pt. 01/ASTM D-445/ASTM D 7042, 100 °C | approx. 14 mm²/s |
ISO viscosity grade, DIN ISO 3448 | 100 |
Viscosity index, DIN ISO 2909 | >= 150 |
Copper corrosion, DIN EN ISO 2160, 3 h/100 °C | 1 - 100 corrosion degree |
Anticorrosive properties on steel, DIN ISO 7120, method A, steel, 24 h/60 °C | no rust corrosion degree |
Pour point, DIN ISO 3016 | <= -40 °C |
Ageing properties, ASTM D 2893, increase in viscosity | <= 6 % |
FZG scuffing test, DIN ISO 14635-1, A/8.3/90, scuffing load stage | >= 14 |
FZG scuffing test, based on DIN ISO 14635-1, A/16.6/90, scuffing load stage | >= 12 |
FAG FE8 rolling bearing test, DIN 51819-3, D 7,5/80-80, wear of rolling element | <= 30 mg |
FAG FE8 rolling bearing test, DIN 51819-3, D 7,5/80-80, wear of cage | <= 200 mg |
Minimum shelf life the date of manufacture | 24 months |
Application.
Klubersynth GEM 4-100 N was specially developed for the lubrication of spur, bevel, hypoid and planetary gears that are subject to high loads. Such gears are frequently used in the wind, steel, mining and sugar industries. It is also used for the lubrication of standard worm gears as defined in DIN 3996.
Klubersynth GEM 4-100 N can also be used for the lubrication of plain and rolling bearings, all kinds of toothed couplings, chains, guideways, joints, spindles and pumps, especially in applications where the equipment is exposed to elevated temperatures or pronounced temperature fluctuations
Application notes
Klubersynth GEM 4-100 N can be applied by means of immersion, immersion circulation or injection.
The use of drip-feed oilers, brushes, oil cans or suitable automatic lubricating systems is also possible. When using automatic lubricating systems, please note the manufacturer's instructions regarding the maximum permissible viscosity. The low-viscosity varieties are also used for oil mist lubrication.
It is miscible with mineral oils. However, for the GEM 4-100 N oil to deliver its full performance, any residues of a previously used mineral oil should not exceed 5 % in quantity. For use at permanent temperatures of 80 °C max., seals made of NBR may be used. For higher temperatures, seals made of FKM should be chosen. It should be noted that elastomers one or several manufacturers can behave differently; therefore tests should be performed. For checking the contact pattern during running-in, the inspection paint Klübertop P 39-462 Spray (Art. No. 081295) can be used.
