Kluberalfa DH 3-100 description.
- Kluberalfa lubricants, based on perfluorinated polyether (PFPE), were developed to fulfil lifetime lubrication under demanding conditions and offer a number of characteristics that make them highly suitable for such tasks.
- Kluberalfa DH 3-100 oils contain a PFPE oil mixture with excellent thermal stability and low evaporation rate.
- They are available with different viscosities to cover various temperature ranges.
Kluberalfa DH 3-100 Benefits for your application.
- Long component life across a wide service temperature range
- Due to excellent thermal and chemical stability
- Many component materials can be used
- Due to the good compatibility with plastics and elastomers
Kluberalfa DH 3-100 technical data.
Product data | Klüberalfa DH 3-100 |
---|---|
Article number | 090067 |
NSF-H1 reg. no. | 155 602 |
Chemical composition, type of oil | PFPE |
Lower service temperature | -25 °C / -13 °F |
Upper service temperature | 180 °C / 356 °F |
Density, DIN 51757, 20 °C | approx. 1.89 g/cm³ |
Refraction index, DIN 51423 pt. 02, at 20 °C | approx. 1.28 |
Kinematic viscosity, 40 °C | approx. 100 mm²/s |
Kinematic viscosity, 100 °C | approx. 12 mm²/s |
Viscosity index, DIN ISO 2909 | approx. 114 |
Pour point, DIN ISO 3016 | <= -40 °C |
Minimum shelf life . | 60 months |
Kluberalfa DH 3-100 Application.
Sintered metal components.
- Kluberalfa DH 3-100 oils are used for the impregnation of sintered metal plain bearings subject to high temperatures where long term lubrication is required.
- Due to their high thermal and chemical stability, additional lubrication with, for example, MIKROZELLA is normally not necessary.
Plastic components.
- Kluberalfa DH 3-100 oils are suitable for the lubrication of both plastic components and metal-plastic sliding contact surfaces. These clear, colourless and odourless oils do not form unwanted resins.
- They are generally regarded as neutral towards elastomers and plastics (possible exception: perfluorinated rubber), so no negative effect on the material is to be expected. Nevertheless compatibility with the materials should be tested, especially prior to series application
Kluberalfa DH 3-100 Application notes.
- Sintered metal components are impregnated by immersion in the Kluberalfa DH 3-100.The oil bath can be heated up to a maximum of 80 °C, during which the immersion tank is subjected to a low vacuum of 0.1 to 0.001 bar, accelerating penetration.
- The sintered-metal component is completely filled with oil when no more air bubbles are expelled to the oil surface.
Where to buy Kluberalfa DH 3-100 ?
As an authorized distributor, Hicotech provides genuine Kluberalfa DH 3-100 and various other industrial products including lubricating oils, greases, chemicals, and more. We offer consultation services and competitive pricing. Please don't hesitate to contact us for further information.
