Klubersynth AR 34-401 Description
- Klubersynth AR 34-401 is NSF H1 registered and therefore complies with FDA 21 CFR § 178.3570. The lubricant was developed for incidental contact with products and packaging materials in the food-processing, cosmetics, pharmaceutical or animal feed industries.
- The use of Klübersynth AR 34-401 can contribute to increase reliability of your production processes. We nevertheless recommend conducting an additional risk analysis, e.g. HACCP.
Benefits for your application
- Reduces friction and wear in pneumatic components
- Low breakaway torque, even after longer periods of standstill ("Monday morning effect")
- Suitable for all types of pneumatic components, preferably those made of NBR but also of PU materials
- Wide piston speed range approx. 0.01 to 1m/s and much more in individual cases.
- Light colour, adhesive.
Klubersynth AR 34-401, Technical data.
Product data | Klübersynth AR 34-401 |
---|---|
Article number | 017153 |
Lower service temperature | -40 °C / -40 °F |
Upper service temperature | 120 °C / 248 °F |
Colour space | beige |
Density at 20 °C | approx. 0.90 g/cm³ |
Worked penetration, DIN ISO 2137, 25 °C, lower limit value | 310 x 0.1 mm |
Worked penetration, DIN ISO 2137, 25 °C, upper limit value | 340 x 0.1 mm |
NLGI grade, DIN 51818 | 1 |
Copper corrosion, DIN 51811, (lubricating grease), 24h/100°C | <= 2 - 100 corrosion degree |
Oil separation, DIN 51817 N, after 7 d/40 °C | <= 3.5 % by weight |
Drop point, DIN ISO 2176, IP 396 | >= 200 °C |
Minimum shelf life the date of manufacture - in a dry, frost-free place and in the unopened original container, approx. | 24 months |
Klubersynth AR 34-401 Application.
- Klubersynth AR 34-401 is primarily used for pneumatic control and sealing elements in compressed air systems. It is commonly employed in ISO single-acting and double-acting pneumatic cylinders, both with and without piston rods, as well as pneumatic rotary actuators and short-stroke or compact cylinders. The grease is also well-suited for valves and their corresponding sealing components.
- This lubricant offers a wide range of piston speeds, ranging approximately 0.01 m/s to over 1 m/s. It provides several advantages, such as low breakaway torque even after prolonged periods of inactivity and reduced tendency to stick-slip at very low piston speeds.
- Klubersynth AR 34-401 is especially effective when used in combination with various types of piston, rod, and damping seals made of NBR or PU elastomer materials. However, please note that it is not specifically approved for use as a lubricant for gas burning installations and actuators according to DIN EN 377 class D.
Klubersynth AR 34-401, Application notes
- For the application of Klubersynth AR 34-401, it can be applied using various methods such as a brush, sponge, spatula, grease gun, or other conventional metering systems. When lubricating cylinder faces, using round brushes or automatic greasing pistons has proven to be effective.
- After assembly, it is important to move the piston several times over the full stroke length to ensure that both sides of the sealing elements are adequately lubricated, especially if one-sided lubrication was the only option. The same procedure applies to valves.
- In some cases, applying slightly more lubricant than needed to the piston seal after multiple strokes can result in a more uniform grease layer, depending on the size and circumference of the application. It is essential to apply the lubricant to a clean, grease-free surface to achieve optimal performance.
Where to buy Klubersynth AR 34-401 ?
Hicotech, are an authorized distributor of genuine Klubersynth AR 34-401 and other industrial products such as lubricating oils, greases, chemicals, etc. For consultation and competitive pricing, please feel free to contact us.
